Afumex Cable Class 500V ES05Z1-K 1X1 Grey - Box of 200 Metres

Afumex — Afumex ES05Z1‑K 500V 1x1 Grey Cable - 200 Meter Box

Applications

• Internal wiring of equipment at 300/500 V.
• Installations requiring LSZH.

Construction

• Class 5 Cu conductor, LSZH insulation.
• Low smoke and corrosive emissions.

Advantages

• Enhances safety in enclosed indoor spaces.
• Easy to strip and connect.

Installation and Use

Install according to REBT and applicable local regulations. Observe the cross-section, permissible current, and minimum bending radius as per the cable designation and installation method.

Key Data

• Designation: ES05Z1-K.
• Rated voltage: 500V.
• Configuration: 1x1.
• Color: Grey.
• 200 meter box.
• Brand/Family: Afumex.
• Halogen-free: Yes.

Documentation

Technical datasheet and certificate available upon request.

Note: Weight and external dimensions may vary due to manufacturing tolerances. Refer to the technical datasheet for exact values.
